Tektronix MSO70000 Series Programmer's Manual

Command Groups
Command
Description
SEARCH:SEARCH<x>:TRIGger:A:SETHold:
HOLDTime
Sets or returns the hold time setting for a
setup/hold trigger search to determine where
to place a mark
. <x> is the search number
SEARCH:SEAR
CH<x>:TRIGger:A:SETH o ld:
SETTime
Sets or retur
ns the s etup time setting for a
setup/hold trigger search to determine where
to place a mark. <x> is the search number
SEARCH:SEARCH<x>:TRIGger:A:STATE:
CLOCk:EDGE
Sets or returns the clock slope setting for a
state trigg
er search to determine where to
place a mark. <x> is the search number
SEARCH:SEARCH<x>:TRIGger:A:STATE:
CLOCk:SOUrce
Sets or returns the clock source of the
twelve waveforms for a state trigger search
to determ
inewheretoplaceamark.<x>is
the search number. The hardware trigger is
always on the channel CH4
SEARCH:SEARCH<x>:TRIGger:A:STATE:
WHEn
Sets or queries the state trigger search to
determi
ne where to place a mark.
<x> is
the search number
SEARCH:SEARCH<x>:TRIGger:A:TIMEOut:
POLarity:CH<x>
Sets or returns the polarity for a timeout
trigger search to determine where to place a
mark. <
x> is the search number or channel
number
SEARCH:SEARCH<x>:TRIGger:A:TIMEOut:
POLarity:MATH<x>
Sets or returns the polarity for a timeout
trigger search to determine where to place
amark
. <x> is the search number or math
waveform number
SEARCH:SEARCH<x>:TRIGger:A:TIMEOut:
POLarity:REF<x>
Sets or returns the polarity for a timeout
trigger search to determine where to place a
mark
. <x> is the search number or reference
waveform number
SEARCH:SEARCH<x>:TRIGger:A:TIMEOut:
TIMe
Sets or returns the tim e setting for a timeout
trigger search to determine where to place a
ma
rk. <x> is the search number
SE
ARCH:SEARCH<x>:TRIGger:A:
TRANsition:DELTATime
Se
ts or returns the transition time setting
for a transition trigger search to determine
where to place a mark.<x> is the search
n
umber
S
EARCH:SEARCH<x>:TRIGger:A:
TRANsition:POLarity:CH<x>
S
ets or returns the polarity setting for a
transition trigger search to determine where
to place a mark. <x> is the search number
or channel number
SEARCH:SEARCH<x>:TRIGger:A:
TRANsition:POLarity:MATH<x>
Sets or returns the polarity setting for a
transition trigger search to determine where
to place a mark. <x> is the search number
or math waveform number
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-51
