Oscilloscope Reference Low reference
Low reference
The Low Reference defines the low reference level of a waveform; the default level is 10%. This reference
level is used w ith the High Reference level in the calculation of rise and fall times. To change this level,
click the con
trol and then, set the level with the multipurpose knob.
Enable mask autoset autofit
From the Mask menu, highlight Mask Configure; then select Autos et. From the Mask Setup control
window, cl
ick the Autoset Config button.
Overview
Use this control to minimize hits.
To use
Click the AutofitOncebuttontoautofit the waveform after autoset is performed.
Behavior
When Autofit is turned on, the w aveform is autofitted once at the end of every autoset. Autoset will take
longer but hits will be minimized. Autofit will only move the signal if there are mask h its.
What do you want to do next?
Learn about trigger level autoset. (see page 855)
L
earn about vertical autoset.
(see page 856)
Learn about horizontal autoset. (see page 853)
852 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
