Tektronix MSO70000C/DX User Manual

Oscilloscope Reference Control the mask autoset trigger level
Control the mask autoset trigger level
From the Mask menu, highlight Mask Configure; then select Autoset. From the Mask Setup control
window, click the Autoset Config button.
Overview
Use this con
trol to choose whether to have autoset affect the trigger level.
To use
Click the Trigger Level button to turn it off or on.
Behavior
When the Trigger Level control is turned on, the trigger levels are adjusted to match the signal when
autoset is performed.
What do you want to do next?
Learn about autofit for autoset. (see page 852)
Learn about vertical autoset. (see page 856)
Lea
rn about horizontal autoset.
(see page 853)
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 855
