SAVE/RECALL
3–46
THS710A, THS720A, THS730A & THS720P User Manual
Key Points
Saving and Recalling Setups. Whether you save a setup in scope mode
or meter mode, the TekScope instrument stores its complete setup in
nonvolatile memory. When you recall the setup, you will be in the
mode from which the setup was saved.
Recalling the Factory Setup. You can recall the Factory Setup to
initialize the TekScope instrument to a known setup. Appendix B
describes the Factory Setup in detail.
Saving a Waveform. Push the CH 1, CH 2, or MATH button to choose
the waveform to save. Waveform position and scale factors are saved
with each waveform.
Recalling a Waveform. Recall a saved waveform into either Ref A or
Ref B for display. When you recall a saved waveform, the recalled
waveform overwrites the previous Ref A or Ref B waveform.
Saving and Displaying a Waveform in One Step. Using a vertical menu,
you can save a waveform and keep it for display at the same time.
Refer to Ref A or Ref B Vertical Menu on page 3–71 for information
about this capability.
Saving Harmonics Data (THS720P). If you save the channel 1 or
channel 2 waveform while the harmonics display is on, the harmonic
measurements and bargraphs are also saved. When you recall the
waveform, turn the harmonics display on to see the harmonics
measurements and bargraphs.
Saving Power Measurement Data (THS720P). If you save the MATH
waveform while the harmonics display is on, the power measure-
ments are also saved. When you recall the waveform, turn the
harmonics display on to see the power measurements.
