Tektronix TekScope THS710A User Manual

TRIGGER Controls
THS710A, THS720A, THS730A & THS720P User Manual
3–55
Edge or Motor
Choose Ch 1, Ch 2,
or External (Edge
only)
Positive
Negative
DC
HF
Reject
LF
Reject
Noise Rej (DC Low
Sensitivity)
Slope SourceCoupling
Pulse Video
Polarity & width SourceTrigger when
Less
Than Width
Greater
Than Width
2
Set tolerance
Source
NTSC
Odd Field
3
(Interlaced)
Even Field
3
(Interlaced)
Any Field
3
(Non-interlaced)
Video Class
Choose Ch 1 or Ch 2 Choose Ch 1 or Ch 2
Positive
1
Negative
1
1
Set pulse width with
+
/– rocker
Equal To
Width
2
Not Equal
To Width
2
Trigger on
PAL
SECAM
Custom Scan
Rate
4
Lines
(Ch1 or Ch2)
3
Choose line with
+
/– rocker
4
Set scan rate with
+
/– rocker
