Tektronix TekScope THS710A

Appendix A: Specifications
THS710A, THS720A, THS730A & THS720P User Manual
A–3
Oscilloscope Specifications (Cont.)
Vertical
Number of Channels 2
Digitizers 8 bit resolution, separate digitizers for each channel sample
simultaneously
VOLTS/DIV Range 5 mV/div to 50 V/div at input BNC
Polarity Normal and Invert
Position Range ±10 divisions
n
A
nalog
B
an
d
wi
d
th
BNC DC C ed
THS710A THS720A THS720P THS730A
at
BNC
,
DC
C
oupl
ed
(typical at 5 mV/div;
guaranteed at all other
settings)
60 MHz at
input BNC
100 MHz at
input BNC
(90 MHz
above 35° C)
100 MHz at
input BNC
(90 MHz
above 35° C)
200 MHz at
input BNC
(180 MHz
above 35° C)
P
e
ak
De
t
e
ct o
r
Env
e
-
eB d d
THS710A THS720A THS720P THS730A
lop
e
B
an
d
wi
d
th, typical
(25 MS/s or slower)
50 MHz
75 MHz 75 MHz 85 MHz
Analog Bandwidth
Limit, typical
Selectable between 20 MHz or full
Lower Frequency Limit,
AC Coupled, typical
≤10 Hz at BNC, reduced by a factor of ten when using a 10X
passive probe
R
i
se
T
i
me
at
BNC
, THS710A THS720A THS720P THS730A
typical
5.8 ns
3.5 ns 3.5 ns 1.75 ns
Peak Detect or Enve-
lope Pulse Response,
typical
Captures 50% or greater amplitude of pulses ≥ 8 ns wide
(≥ 20 ns wide at 500 ns/div)
DC Gain Accuracy ±2% for Sample or Average acquisition mode
Position Accuracy ±[0.4% × |(position × volts/div)| + (0.1 div × volts/div)]
