DMM Specifications (Cont.)
DC Voltage
n Accuracy
±(0.5% of reading + 5 counts)
Normal Mode
Rejection, typical
Rejects AC signals by >60 dB at 50 Hz or 60 Hz (user selectable)
Common Mode
Rejection, typical
Rejects AC signals by >100 dB at 50 Hz or 60 Hz (user
selectable)
AC Voltage
Conversion Type AC conversions are true RMS. The AC measurement is based
on the AC and DC components of the signal as shown below:
AC Measurement = RMS(AC+DC) – DC
R
ang
es
an
d
Res
olution Range Resolution
400.0 mV 0.1 mV
4.000 V 1 mV
40.00 V 10 mV
400.0 V 100 mV
640 V 1 V
n
A
ccu
r
acy
000
Input Waveform Maximum Error
(4
0
Hz to 5
00
Hz)
Sinusoidal waveforms with no
DC component
±(2% of reading + 5 counts)
Nonsinusoidal waveforms with
crest factor up to 3 and no DC
component
±(4% of reading + 5 counts)
Common Mode
Rejection, typical
Rejects AC signals by >60 dB at DC, 50 Hz, and 60 Hz
