Tektronix TekScope THS710A User Manual

Appendix A: Specifications
THS710A, THS720A, THS730A & THS720P User Manual
A–15
DMM Specifications (Cont.)
Continuity Check
Indication, typical An audible tone is generated when measured resistance is below
50 
Open Circuit Voltage,
typical
4 V
Test Current, typical 1 mA
Diode Check
Range Zero to 2 V, measures forward voltage drop of semiconductor
junction
Voltage Accuracy,
typical
±25%
Open Circuit Voltage,
typical
4 V
Test Current, typical 1 mA
Data Logger
Horizontal Scale
Range
30 s/div to 24 hours/div (4 minutes to 8 days, full scale)
Vertical Zoom Range 2X, 5X, or 10X
General Specifications
Display
Display Type 4.7 in (120 mm) diagonal liquid crystal
Display Resolution 320 horizontal by 240 vertical pixels
Display Contrast Adjustable, temperature compensated
Backlight Intensity,
typical
35 cd/m
2
