Introduction
The AUTO/MANUA
L submenu. This submenu allows you to set the cursors to auto
adjust or manual adjust This menu is only available when the rise time or fall
time cursor is s elected.
The 1, 2, 3, 4, M, OFF submenu. This submenu allows you to select to which
channel to apply the cursor or to turn the cursor off for a selected channel. Each
number corresponds to the channel number.
Enter
Use the Enter button to select menu items.
Level
The Level b
utton a llows you to adjust the trigger input level.
Menu Off
The Menu Off button allows you to hide any menu from the display. Press the
button again to view the same menu.
Position (horizontal)
Use the Position horizontal button to move a waveform left or right along the
display grid.
Position (vertical)
Use the Position verticalbuttontomoveawaveformupordownalongthe
display grid.
Run/Stop
Press the Run/Stop button to start and stop acquisition. When acquisition is
running, the word RUN is displayed in the top right corner of the display screen
outlined in green. When acquisition is stopped, the word STOP is displayed in the
top right corner of the d isplay screen outlined in red.
Save
The Save button allows you to save, recall, copy, move, rename, and delete
screens and setups to internal instrument memory or to the USB device as follows:
1
Maximum USB memory size supported is 2 GB
The SAVE menu. This menu allows you to select what to save where.
MEMORY: Select from INT (internal instrument memory) or USB (USB
memory device).
SavetoINT(orUSB):SelecttosaveScreen+SetuporReplay+Setupto
internal instrument memory or USB device.
The RECALL menu. This menu allows you to recall DATA or SETUP from
internal or USB device memory.
6 THS3000 Series Oscilloscopes User Manual
