Save and Recall
Rename Stored Screens
and Setup Files
To rename a stor
ed screen + setup file, do the following:
1
1. Press the Save button. Once the menu appears, the display screen will be
frozen.
2. Select FILE OPTIONS....
3. Select the target memory: INT (internal memory) or USB (USB device).
4. Use the down arrow key to highlight RENAME.
5. Press the Enter button.
6. Use the down arrow key to highlight the file you want to rename, and then
press the Enter button.
7. Use the arrow keys to select a letter, number, or character. Use the function
keys under PREV # and NEXT # to move the cursor to the next letter in the
name to change that letter.
8. Select NAME OK to save the new name and return to t he previous menu.
9. Press the Run/Stop button to exit the Save menu and resume measurements.
THS3000 Series Oscilloscopes User Manual 77
