SeaBat Sonar UI - User Manual Appendix Raw Data Recording (RDR)



Step

Action

Open the windows Control panel.

Open ‘System’

a. A overview is listed with the computer name and current

Workgroup(name).

b. Click ‘Change settings’ to modify.

Followed by clicking ‘Change’.
