Appendix Raw Data Recording (RDR) SeaBat Sonar UI - User Manual

Step

Action

a. Tick the checkbox ‘use the following IP address’.

b. Enter the IP address. (In this example 10.4.0.1).

c. Enter subnet mask 255.255.255.0

d. Click ‘OK’.

7.5 File sharing

The folder to store the RDR needs to be shared.

The table below summarizes the procedure.

Step

Action

Open Windows Explorer.

Make or create a new folder to be shared.
