SeaBat Sonar UI - User Manual Appendix Raw Data Recording (RDR)



101

Step

Action

Click ‘Change adapter settings’.

An overview will be listed with available ports. A Local Area

connection should be listed with status ‘Connected’. Check the

network connection cable between the processor/computer

when status is ‘disconnected’.

Right click at this ‘local area connections’ icon.

Open the ‘Properties’ from the context menu.

Double click ‘Internet Protocol Version 4 (TCP/Ipv4)’.
