B-2
System Specifications
System Operating Ranges
System Operating Ranges are the ranges in which parameter measurement performance
meets system accuracy limits when adhering to instructions for use.
ParameterParameter Operating RangeOperating Range
pH 6.80 to 7.65
pCO
2
10 to 80 mmHg
pO
2
20 to 500 mmHg
K
+
3.0 to 8.0 mmol/L
Shunt Temp 15° to 40° C
SO
2
60 to 100%
HCT 15 to 45%
Hgb 5 to 15 g/dL
Q
Per tubing size:
3/8” 0.20 to 8.00 L/min
1/4” 0.05 to 2.50 L/min
Note: The system is intended to be used only within the above “System Operating
Ranges” for the System Accuracy Limits. Values outside of these ranges will be displayed
and an alarm will be triggered, except for BE, Temperature and Arterial SO
2
.
