B-17
System Specifications
Physical Specifications
Component Part # Dimensions Weight
Core CDI750 22.2 cm x 27.2 cm x 8.3 cm 3 kg
Display + Backplate CDI751 30 cm x 20.5 cm x 9.5 cm 2.4 kg
Calibrator CDI740 23 cm x 21 cm x 18 cm 3.3 kg
Brackets CDI780 21 cm x 15.5 cm x 12 cm 1.6 kg
CDI781 47 cm x 28 cm x 9 cm 1.7 kg
CDI782 32.4 cm x 18.6 cm x 8.2 cm 1 kg
CDI783 19.2 cm x 9 cm x 5.8 cm 1 kg
Safe Working LoadsSafe Working Loads
Brackets Part # Weight
Core CDI780 10 kg
Display CDI781 7 kg
BPM CDI782 3.2 kg
Calibrator CDI783 10 kg
Maximum Viewing Angles (As Measured from Normal)
Horizontal ±80 degrees
Vertical +65, -80 degrees
Note: All dimensions are approximate and may vary slightly from product to product.
Priming Volumes
Module Volume
Model CDI510H Shunt Sensor 1.2 mL
1/4" CDI H/S Cuvettes 4 mL
3/8" CDI H/S Cuvettes 9 mL
1/2" CDI H/S Cuvettes 16 mL
