B-7
System Specifications
Electrical Specifications
Core PowerCore Power
AC 100-240 VAC
50/60 Hz
170 VA
Battery Type: Lithium-ion
Voltage: 14.4 VDC
Operating time: 25 minutes under maximum load
Compliance: IEC 62133, PSE
Note: To provide isolation from supply mains, remove power cord from the CDI
OneView System appliance coupler. Do not position the CDI OneView System so that it
is difcult to isolate the appliance coupler from the supply mains.
Device ClassificationDevice Classification
Electric Shock Protection Class I
Debrillator-proof type CF applied part
Electromagnetic Emissions Group 1/Class A with respect to CISPR 11
Mode of Operation Continuous
Electromagnetic Compatibility IEC 60601-1-2:2014+A1:2020
IEC 80601-2-49:2018
Ingress ProtectionIngress Protection IP RatingIP Rating
Display and Core IP32
BPM Probe IPX4
Calibrator, H/S Probe, Modules, Flow
Sensor
IPX2
