Symbols Glossary
The following symbols may appear in the labeling, marking or display of the CDI
OneView. These symbols are in accordance with the internationally harmonized
standards.
Symbol Title Description Source
Operator’s Manual;
operating instructions
To indicate that the operating
instructions should be considered
when operating the device or control
close to where the symbol is placed.
ISO 7000-1641
Refer to instruction
manual/booklet
To signify that the instruction
manual/booklet must be read.
ISO 7010-M002
Warning
Indicates the need for the user to
consult the instructions for use for
important warnings that cannot be
presented on the medical device itself.
ISO 7010-W001
Caution
Indicates the need for the user to
consult the instructions for use for
important precautions that cannot be
presented on the medical device itself.
ISO 15223-1-5.4.4
Protective earth
ground
Protective earth ground. IEC 60417-5019
Debrillation - Proof
Type CF Applied Part
Patient applied part. IEC 60417-5336
Alternating current
To indicate on the rating plate that the
equipment is suitable for alternating
current only; to identify relevant
terminals.
IEC 60417-5032
Direct current Direct current. IEC 60417-5031
Equipotentiality Equipotentiality. IEC 60417-5021
Fuse Fuse. IEC 60417-5016
IP32
Protected against
direct sprays of water
up to 15 degrees from
vertical
Protected from tools
and wires greater than
2.5 millimeters
Drip proof in accordance with IEC
60529.
IEC 60529
IPX2
Protected against
vertically falling water
drops when enclosure
tilted up to 15°
Drip proof in accordance with IEC
60529.
IEC 60529
IPX4
Resistant against water
from any direction
Water Resistant in accordance with
IEC 60529.
IEC 60529
e PSE mark will be
on the fuse
Design compliance to Law No. 234 of
1961.
Denan Guide for
compliance with
Japan Regulations
