TESA MICRO-HITE - Line through 2 Points; Bestfit Line; Circle through 3 Points; Bestfit Circle

Instruction manual for MH & MH+M
127
19.14 Line through 2
points
It is possible to construct a perfect line using action if the following two blocks as
selected:
• Two points
• Two circles
• A point and a circle
19.15 Bestfit line
A bestfit line is a line being calculated from three blocks (or more) being either points or
circles (or a mix of both). This line minimises the D1, D2, D3, D4 et D5 distances (in our
below example for instance).
A best fit line can be calculated via the action.
19.16 Circle through 3
points
It is possible to construct a perfect circle with action if the following three blocks have been
selected:
• Three points
• Three circles
• A combination of three blocks with
points and circles
19.17 Bestfit circle
A bestfit circle is a circle calculated from a selection of four blocks (or more). These blocks
are either points or circles (or a mix between both). This circle minimises D1, D2, D3, D4 et
D5 distances (in our below example for instance).
