21.7 *.Pdf report
With the MICRO-HITE or MICRO-HITE+M height gauge, reports in *.pdf format can be
created on the USB key connected to its panel. The creation can be done:
• automatically after the execution of a measurement programme
• manually when the user selects the action to create the *.pdf file in the context-based
action bar
The user can define the process for the report management from the system options
menu.
Header
The measurement report has a header containing the following information:
What
Note
Operator's name
Is editable in the system options menu
Company name
Is editable in the system options menu
Part name
The program name is used as the part name
Batch name
Is editable in the system options menu
Date
-
Time
-
Company logo
The file named company_logo.jpg stored in the root folder of the
USB stick is taken into account.
The company logo is not compulsory. If the panel does not find
any logo when creating the document, the area dedicated to the
header will be automatically adjusted.
Image of the part
The image of the part can be inserted at the beginning of a measurement report. As for the
company logo in the header, the software will check when creating the document, if a file
corresponding to the executed program exists at the root of the USB key. If this is the
case, the image will be taken into account, otherwise the document will be adjusted
accordingly.
Please note that the system is flexible. Indeed, it is possible to have several programs
stored on the USB key and for each program a different image to display on the
measurement report.
An image must bear the same name as the program to be taken into account when
creating a *.pdf measurement report at the end of the sequence execution. Here are some
examples:
Name of the program
Name of the image stored in the root folder of the
USB key
Piece_TESA.st1
test123.st2
Sample report:
