Process
1. Move the probe using the handwheel. Make sure you do not hit anything (probe, probe
support etc.) during the movement.
2. Position the probe close to the point to be measured.
3. Once the location of the measurement is clearly defined, put the probe in contact with
the surface. Continue to apply pressure on the insert (and make sure that the strain
gauge is still in the green zone) until the point is captured.
4. Release the system, so that the probe is not in contact with the workpiece any more.
5. Visualise the result on the screen.
