HYDRAULICS
8D-17
Control Group Assembly
See Figure 8D-13 for control group assembly.
Figure 8D-13. Control Group Assembly
Gasket
Control Pin
O-Ring
Control
Housing
O-Ring
Arm and Pintle
Traction Pump
Assembly
