OPTIONS
13C-13
Bearing Adjustment
1. Remove the nylon clamp and loosen the capscrew
on the end of the groomer shaft (Figure 13C-8).
2. Pull the groomer mounting bracket out, away from
the cutting unit. You will see a gap between the
inner and outer groomer brackets.
3. Slowly tighten the capscrew (C) on the end of the
groomer shaft until the outer groomer bracket is
pulled in against the inner bracket and the gap
closes.
4. Using two wrenches, hold the cutter retaining nut
(A) and slowly turn the bearing adjustment nut (B)
until it just contacts the bearing spacer, slight
resistance will be felt.
5. Torque the capscrew (C) on the end of the
groomer shaft to 20ft-lbs (27 Nm).
6. Install the nylon clamp, torque to 5 ft-lbs (6.7 Nm).
Figure 13C-8. Bearing Adjustment
