Thales 421 - Fig. 8−6 Configuration of the Test Points

LLZ 421
Alignment Procedure LLZ−2F (LPD) Operation and Maintenance
ILS 420
8−24 Ed. 07.08SOAC
B
C
107 m* 107 m*
+40°
−40°
approx. 1000 m
150 Hz
90 Hz
AA’
LLZ antenna
approx. 150 m
Not to scale
* calculated according to 15.5 % DDM
D
1...2° 1...2°
Fig. 8−6 Configuration of the test points
