Thales 421 - Fig. 3−8 EXE−SDM Select and Monitor Exec. SDM Window (Example)

LLZ 421
Operation and Maintenance Operation
ILS 420
3−13Ed. 01.10
SOAC
− In the Monitor Exec. SDM window the following button definitions are used:
S1 MENU to go to Menu List window (see Fig. 3−15)
S2 EXE-DDM to change to Monitor Exec. DDM window (see Fig. 3−7)
S3 STBY-SDM to change to Monitor Standby SDM window (see Fig. 3−9)
S4 STATUS to return to the Status window (see Fig. 3−6)
1
4
2
3
1
4
2
3
AERIAL: TX2 / ON AERIAL−SDM
1 MONITOR 2
BYPASSED BYPASSED
CRS POSITION
SDM % 79.7 79.7
CRS WIDTH
SDM % 79.8 79.7
CLR WIDTH
SDM % 80.0 80.0
NEARFIELD
SDM % Z Z
FARFIELD
SDM % Z Z
MENU EXE−DDM STBY−SDM STATUS
*
AERIAL: TX2 / ON AERIAL−DDM
1 MONITOR 2
BYPASSED BYPASSED
CRS POSITION
DDM % 0.0 0.0
CRS WIDTH
DDM % 15.4 15.4
CLR WIDTH
DDM % 23.9 23.7
NEARFIELD
DDM % Z Z
FARFIELD
DDM % Z Z
MENU STBY−DDM EXE−SDM STATUS
*
*
*
*
control buttons (S)
* depends on configuration
Fig. 3−8 EXE−SDM select and Monitor Exec. SDM window (example)
− In the Monitor Standby SDM
window the following button definitions are used:
S1 MENU to go to Menu List window (see Fig. 3−15)
S2 STBY-DDM to change to Monitor Standby DDM window (see Fig. 3−10)
S3 EXE-SDM to change to Monitor Exec. SDM window (see Fig. 3−8)
S4 STATUS to return to the Status window (see Fig. 3−6)
1
4
2
3
1
4
2
3
LOAD: TX1 / ON STANDBY−SDM
1 MONITOR 2
BYPASSED BYPASSED
CRS POSITION
SDM % 79.7 79.7
CRS WIDTH
SDM % 79.3 79.4
CLR WIDTH
SDM % 80.0 80.1
MENU STBY−DDM EXE−SDM STATUS
*
AERIAL: TX2 / ON AERIAL−SDM
1 MONITOR 2
BYPASSED BYPASSED
CRS POSITION
SDM % 79.7 79.7
CRS WIDTH
SDM % 79.8 79.7
CLR WIDTH
SDM % 80.0 80.0
NEARFIELD
SDM % Z Z
FARFIELD
SDM % Z Z
MENU EXE−DDM STBY−SDM STATUS
*
*
control buttons (S)
* depends on configuration
Fig. 3−9 STBY−SDM select and Monitor Standby SDM window (example)
