Navaids 400
Operation and Maintenance General Information
1−7
Ed. 01.04
SOAC
ILS CVOR DVOR Marker
Designation Code No . Remarks/Type
Digital Voltmeter 97991 28217 x x x
Dual trace oscilloscope 97991 28454 TDS 360 x x x x
Thruline Wattmeter 97991 28040 0.45...2300 MHz x x x x
Monitor dipole, mobile 58317 24019 x
Dipole 60 cm 38826 28006 x
Mon. dipole add. parts mobile 83131 72409 x
Tripod 19614 72801 G5K, No. 1151 x
VOR−Monitor signal simulator 83134 31600 x
ILS/VOR signal analyzer 97991 28447 7010 portable x x
Attenuator 100 W/30 dB 49901 28051 50 Ohm
 RBU100.8654.37 x
Probe 19983 15001 x
Measuring element 50 W 97991 28043 50 C, Bird, 100...250 MHz x x x
Measuring element 25 W 97991 28111 25 D, Bird, 200...500 MHz x
Measuring element 10 W 97980 28193 10 C, Bird, 100...250 MHz x x
Measuring element 5 W 97991 28112 5 D, Bird, 200...500 MHz x
Measuring element 1 W 97991 28192 095−1, Bird, 275...450 MHz x
Measuring element 1 W 97991 28193 275−1, Bird, 100...250 MHz x x x
Measuring element 5 W 97991 28041 5 C, Bird, 100...250 MHz x x
Measuring element 100 W 97991 28182 100 C, Bird, 100...250 MHz x x
Directional coupler 97991 28273 HP 778 D x x x
Terminating resistor 97991 28274 HP 8491 A, 30 dB, opt. 30 x x x
Attenuator 100 W/30 dB 97499 28007 50 Ohm
 BN 745395 x x x
3−dB−coupler 49901 23002 CH−132, M.SMA x x x
VHF−dummy load 1 W 24338 20401 50 Ohm, BN753790 x
Attenuator 20 dB/3,5 W 49901 20402 50 Ohm
 BN654104 x x x
Attenuator 10 dB/1 W 49901 20405 50 Ohm
 R414510 TNC x x x
Attenuator 6 dB/2.5 W 49901 20403 50 Ohm
 R414506 TNC x x x
Attenuator 20 dB/1 W 49901 20406 50 Ohm
 R414520 TNC x x x
Attenuator 10 dB/10 W 49901 28044 50 Ohm
 BN745383 x −
Adapter 24334 20323 TNC male/fem. BN150419 x x x
Adapter 24334 20342 TNC male/male BN746700 x x x
Adapter 24334 20403 TNC fem./fem. BN746600 x x x
Adapter 24334 20404 BNC male/banana SHU06996 x x x
Adapter 24334 20408 BNC male/TNC fem. BN712100 x x x
Adapter 24334 20409 TNC male/N fem. BN725900 x x x
x = available (optional)
