Tomey UD-8000 User Manual

3-221 ■
f) Image Quality
(1) Amp Setting
Selects the gradation characteristic in the B-mode image diagnosis function from Log/S.
(2) Color Setting
Selects the color setting for B-mode image display in this instrument from Monochrome 1,
Monochrome 2, Color 1, and Color 2.
(3) User Setting
Registers the user settings (3 types) available in “Image Quality” in real time B-mode. Registers
the name displayed on the button in real time and the corresponding Total Gain, dynamic range,
Near Gain, and Far Gain values.
1) Touch the “Change Name” button (5) to allow entry.
2) Change the name (6) using the software keyboard.
3-149
(1)
(2)
(3)
(4)
3-150
(5)
(7)
（fig. 2）
(6)
(8)
