■ 3-16
k) Connecting AL-4000
[Built-in connection]
Slowly push and slide the unit to the back.
Note that AL-4000 charges itself through the power supply terminal (1) of
UD-8000 as long as the instrument is housed in the main body of UD-8000
and UD-8000 is turned ON.
Slowly pull out AL-4000 toward you to remove it.
(Fig. 1)
3-16
(1)
