Tomey UD-8000 User Manual

3-41 ■
15 MHz B probe 60MHz UBM probe
The scan mark = the upper side of image
The scan mark = the left side of image
<Understanding the probe angle mark>
The scan direction mark (1) on the B-mode probe is indicated by the extending
section (2) of the probe angle mark.
3-39
(1)
3-41
(Fig. 4)
(Fig. 5)
3-42
(2)
