Topcon GR-5 User Manual

GR-5 Receiver Setup and Survey
GR-5 Operator’s Manual
4-6
Figure 4-3. Antenna Height Measurement Points
Vertical Height
to ARP
Station Marker
or
Tip of RTK Pole
Slant Height
to Base of
Corner on
Gray Bumper
85.0mm
168mm
228mm228mm228mm228mm228mm228mm253.0mm
A
B
A = ARP to edge = 79.0
B = ARP to corner = 97.5
168mm
A
B
A = ARP to edge = 79.0
B = ARP to corner = 97.5
LV LS
SHMM
LV = Vertical Length
LS = Slant Length

Topcon GR-5 Specifications

General

Brand	Topcon
Model	GR-5
Category	Receiver
Language	English
