GR-5 Receiver
P/N 7010-1004
1-21
Other Accessories
The power supply unit (p/n 22-034101-01) charges the internal
batteries when connected to a grounded outlet (Figure 1-8). This unit
converts the alternating current (AC) normally supplied from an
electrical outlet to a direct current (DC) used to charge the batteries
and/or power the receiver.
The power supply unit can be connected to the charging cradle or
directly to the receiver. For details, see the power related sections in
Chapter 2.
Figure 1-8. Power Supply Unit
The power supply unit should only be used for
charging the batteries. Do not use as a power source
during surveying.
