Net-G3A Configuration and Setup
NET-G3A Operator’s Manual
3-4
4. Click Set all parameters to defaults (Figure 3-2).
Figure 3-2. Set All Parameters to Defaults
5. Click the MINTER tab, configure the following settings
(Table 3-1), and then click Apply (Figure 3-3).
Table 3-1. Receiver Parameters for the MINTER Tab
Parameter Setting
Recording interval Enter 15 seconds. (This variable depends on post-
processing requirements.)
Elevation mask
angle
Enter 15 degrees. Five degrees (default value) is
recommended for base operations.
File name prefix Enter the last 3 digits of the receiver’s serial number.
FN key mode (starts/stops data recording using the FN key)
For Static data recording, select LED blink mode switch.
Net-G3A_OM_Book.book Page 4 Thursday, May 14, 2009 8:49 AM
