Toro Groundsmaster 7210 - Jacking Instructions; Raising the Front of the Machine

JackingInstructions
CAUTION
Failingtoproperlysupportthemachinewithappropriatejackstands
cancausethemachinetomoveorfallandcanresultinpersonal
injury.
Whenchangingtheattachments,tires,orperformingotherservices,
dothefollowingsteps:
•Usecorrectblocks,hoists,andjackstoraiseandsupportthe
machine.
•Parkthemachineonasolidlevelsurface,suchasaconcrete
oor.
•Beforeyouliftthemachine,removealltheattachmentsthatmay
interferewiththesafeandcorrectliftofthemachine.
•Alwaysblockthewheelswithchocks.
•Useappropriatejackstandstosupporttheraisedmachine.
•Donotusethecuttingdeck(orimplement)asajackingpoint.
RaisingtheFrontoftheMachine
g033384
Figure2
1.Frontcastorwheel2.Frontjackingpoint
1.Settheparkingbrakeandblockthe2reartireswithchockstopreventthe
machinefrommoving.
2.Positionthejacktothemachine:
A.Onmachineswithcuttingdeck,positionthejackstandsunderthesquare
carrierframetubenearthefrontcastorwheel(Figure2).
B.OnmachineswithPolarTrac™Kit,positionthejacksecurelyunderthe
liftarmpivottubeonthefrontofthemachine.
3.Useajacktoraisethefrontofthemachine.
4.Afterraisingthefrontofthemachine,useappropriatejackstandsunderthe
frametosupportthefrontofthemachine.
Safety:JackingInstructions
Page1–6
Groundsmaster7210
16222SLRevC
