TestingtheDiodeAssembly(continued)
DiodeTestTable
MultimeterRedLead(+)
onTerminal
MultimeterBlackLead
(-)onTerminal
Continuity
FemaleMaleYes
MaleFemaleNo
ResistorAssembly
TheresistorassemblyisusedinalltheenginewireharnessesforGM7210
machinesthatisnecessaryforoperatingthekeyswitch.Theresistorplugsinto
thewiringharnessnearthealternator;refertotheEngineWireHarnessDrawing
inAppendixA—FoldoutDrawings
Theresistorassemblycanbeidentiedbyitsgraycolorandresistorsymbolon
theendoftheresistorassemblybody.
g034715
Figure162
1.Endoftheresistorbody
2.Resistorassembly
TestingtheResistorAssembly
Theresistorcanbetestedusingadigitalmultimeter(ohmssetting).
Note:Theresistanceacrosstheresistorterminalsshouldbe1600ohms.
ElectricalSystem:TestingtheElectricalComponents
Page5–38
Groundsmaster7210
16222SLRevC
