Toro Groundsmaster 7210 Service Manual

Adjustments
ParkingBrakeSensor
g034729
Figure178
1.Parkingbrakelever
5.Lockwasher(2each)
2.Parkingbrakeshaft
6.Bracket
3.Flangebearing7.Parkingbrakesensor
4.Jamnut(2each)
8.T ab
g035039
Figure179
1.Parkingbrakeshaft
3.Parkingbrakesensor
2.T ab
4.Gap
TheparkingbrakesensoractsasaninputfortheSCMcontrollertodetermine
whentheparkingbrakeisset(thebrakelatchengaged).Thebrakesensoris
anormallyopenproximitysensorthatisinstalledtothebracketlocatedbelow
thebrakeshaft(Figure178).
ElectricalSystem:Adjustments
Page5–54
Groundsmaster7210
16222SLRevC
