Toro Groundsmaster 7210 Service Manual

OilCooler
RemovingtheOilCooler
1.Parkthemachineonalevelsurface,lowerthecuttingdeck(orimplement),
shutofftheengine,settheparkingbrake,andremovethekeyfromthe
keyswitch.
2.Unlatchthehoodandraiseit.
CAUTION
Ahotradiatorandoilcoolercancauseburns.
Allowtheengineandcoolingsystemstocoolbeforeworkingonor
nearthem.
3.Removetheradiatorandoilcoolerfromthemachine;refertoRemovingthe
Radiator(page3–13).
4.Removethe3screws(item1inFigure132),6atwashers,3lockwashers,
and3nutsthatattachtheoilcoolertotheradiator.
5.Separatetheoilcoolerfromtheradiator.
InspectingtheOilCooler
1.Backushtheoilcoolerwithcleaningsolvent.Aftercleaningthecooler,
ensurethatallthesolventisdrainedfromthecooler.
CAUTION
Useeyeprotectionsuchasgoggleswhenusingcompressedairto
drytheoilcooler.
HydraulicSystem:ServiceandRepairs
Page4–134
Groundsmaster7210
16222SLRevC

Toro Groundsmaster 7210 Specifications

General

Horsepower	24.8 hp
Drive System	Hydrostatic
Number of Blades	3
Fuel Capacity	12 gallons
Deck Type	7-Gauge High-Strength Steel
Blade Tip Speed	18, 000+ ft/min
Turning Radius	Zero
Cutting Height	1.0" (2.5 cm) to 5.0" (12.7 cm) in 0.5" (1.3 cm) increments
