TestingtheSeatSwitch(continued)
WARNING
Topreventinjury,donotattempttoreachtheswitchthrough
openingsintheseatplate.
Ifseatswitchserviceisnecessary,removetheseatfromtheseat
platetoaccesstheswitch.
F.Ifthecontinuitytestisincorrect,removetheseat;refertotheOperator
Seat(page6–35).Checktheseatswitchand/orseatswitchharnessfor
continuity.Repairorreplacethecomponentsasnecessary.
G.Iftheseatswitchtestingiscorrectandthecircuitproblemstillexists,
checkthemachinewireharness;refertotheElectricalSchematicsand
WireHarnessDrawings/DiagramsinAppendixA—FoldoutDrawings.
H.Afteryoucompletetheseatswitchtesting,connectthemachinewire
harnessconnectortotheseatswitchelectricallead.Lowertheseat
assembly.Checktheoperationoftheseatswitch.
