3.3 Check of the RAID configuration 3 Tests and Diagnostics
NO DRIVE for one drive is displayed
When “NO DORIVE” is displayed and the HDD is connected to the port, follow the
procedures below to check the HDD failure.
(1) Install a new HDD.
When “NO DORIVE” is still displayed, It is judged that the MB or cable fails.
(2) When a new HDD is recognized, It is judged that the HDD removed is failed.
Specify the reason by using the Independent Utility.
TOSHIBA RAID / RAID Information Display Rev xx.xx.xxxx
Copyright(c) 2005 TOSHIBA CORPORATION. All Rights Reserved.
Level Status Capacity
LD0 RAID-1 DEGRADE xxGB
Write cache : Enable
Degrade Bootup : Yes
MBR Protection : Disable
S.M.A.R.T : Enable
Port Assign Status Size Model Rev
0 LD0-0 ONLINE xxGB FUJITSU---------- xxxxxxx
1 NODRIVE xxGB FUJITSU---------- xxxxxxx
< RAID: not OPTIMAL >
3-14 [CONFIDENTIAL] QOSMIO G20 Maintenance Manual (960-511)
