4.3 ExpressCard & PC card / Bridge media 4 Replacement Procedures
4.3 ExpressCard & PC card / Bridge media
4.3.1 ExpressCard & PC card
Removing an ExpressCard & PC card
The following describes the procedure for removing an ExpressCard & PC card (See Figure
4-2).
CAUTION: Insert or remove an Express card & PC card in accordance with any
instructions in their manual or the manuals of the computer system you are
using.
1. Push the eject button. It will pop out when you release it. Then press the eject button
once more to eject an ExpressCard or PC card.
2. Grasp an ExpressCard or PC card and remove it.
NOTE: If an ExpressCard or PC card is not inserted all the way, the eject button may
not pop out. Be sure to push an ExpressCard or PC card firmly and press the
eject button again.
[ExpressCard (Upper slot)]
Eject button
Expresscard
4-10 [CONFIDENTIAL] QOSMIO G20 Maintenance Manual (960-511)
