4 Replacement Procedures 4.3 ExpressCard & PC card / Bridge media
[PC Card (Lower slot)]
Eject button
PC card
Figure 4-2 Removing an ExpressCard or PC card
Installing an ExpressCard & PC card
The following describes the procedure for inserting an ExpressCard & PC card (See Figure
4-2).
1. Make sure the eject button does not stick out.
2. Insert an ExpressCard or PC card and press it until it is securely connected.
QOSMIO G20 Maintenance Manual (960-511) [CONFIDENTIAL] 4-11
