Toshiba Qosmio G20 - 2.5-inch Hard Disk Drive

1.3 2.5-inch Hard Disk Drive 1 Hardware Overview
1.3 2.5-inch Hard Disk Drive
A compact, high-capacity Serial-ATA HDD with a height of 9.5mm. Contains a 2.5-inch
magnetic disk and magnetic heads.
Figure 1-3 shows a view of the 2.5-inch HDD and Tables 1-1 and 1-2 list the specifications.
Figure 1-3 2.5-inch HDD
Table 1-1 2.5-inch HDD dimensions
Standard value
Parameter
FUJITSU
G8BC0001R610
FUJITSU
G8BC0001R810
TOSHIBA
HDD2D30BZK01
Width (mm)
70.0 -
Height (mm)
9.5 -
Depth (mm)
100.0 -
Outline
dimensions
Weight (g)
99 (max) -
1-10 [CONFIDENTIAL] QOSMIO G20 Maintenance Manual (960-511)
