1 Hardware Overview 1.2 System Block Diagram
❑ MODEM (Askey-made 1456VQL4 x 1)
Supported by MDC.
Uses secondary AC97 line.
Data and FAX transmission is available.
Supports ITU-TV.90.
The transfer speed of data receiving is 56kbps, of data sending is 33.6kbps and of
FAX is 14.4kbps. Actual speed depends on the quality of the line used.
Connected to telephone line through RJ11 MODEM jack.
QOSMIO G20 Maintenance Manual (960-511) [CONFIDENTIAL] 1-9
