4 Replacement Procedures 4.2 Battery pack
Installing the battery pack
The following describes the procedure for installing the battery pack (See Figure 4-1).
CAUTION: There is a danger that the lithium ion battery pack may explode if not fitted,
operated, handled, or disposed correctly. Dispose always the used battery
pack in accordance with the laws and ordinances of your local authority.
Use only the batteries approved by Toshiba.
NOTE: Check visually the battery terminals and clean off any dirt with a dry cloth.
1. Turn off the power of the computer.
2. Disconnect the AC adapter and all external devices from the computer.
3. Attach the battery cover to the battery pack.
4. Place the battery pack into the slot from the other side of the connector and insert it
carefully.
5. Slide the battery lock to the lock position.
QOSMIO G20 Maintenance Manual (960-511) [CONFIDENTIAL] 4-9
