4.6 Memory module 4 Replacement Procedures
Installing a memory module
To install a memory module, confirm that the computer is in boot mode. Then perform the
following procedure (See Figure 4-8).
1. Insert a memory module into the connector of the computer slantwise (terminal side
first) and press it to connect firmly.
CAUTION: Be sure to install a memory module to slot A (CN1400). The computer does
not boot when slot A is vacant.
After installing the memory module, confirm that the memory module is fixed
with the left and right latches.
Never press hard or bend a memory module.
2. Install the memory slot cover and secure it with the screw (with e-ring).
3. When the power of the computer is turned on, the computer checks automatically the
memory size. Confirm that the new memory is detected correctly.
4. If the memory is not detected, check that it is connected correctly.
4-20 [CONFIDENTIAL] QOSMIO G20 Maintenance Manual (960-511)
