4 Replacement Procedures 4.21 CPU fin & CPU
NOTE: Apply the silicon grease enough to cover the chip surface using the special
applicator.
Figure 4-34 Applying silicon grease
5. Install the CPU fin and CPU holder and secure them with the following screws.
 M2.0x4.0C BIND screw x3
NOTE: When securing the CPU holder, be sure to secure the screws in the order of the
number marked on the holder.
QOSMIO G20 Maintenance Manual (960-511) [CONFIDENTIAL] 4-55
