4 Replacement Procedures 4.22 VGA fan & VGA fin
Installing the VGA fan & VGA fin
The following describes the procedure for installing the VGA fan & VGA fin (See Figure 4-
35).
1. Install the VGA fin.
NOTE: For details on applying the silicon grease, refer to “Installing the CPU”.
2. Secure the VGA fin with the following screws.
M2.0x3.0S S-THIN FLAT BIND screw x2
3. Install the VGA fan and secure it with the following screws.
M2.5x4.0B FLAT BIND screw x2
4. Connect the VGA fan cable to the connector CN8780 on the system board and stick
the glass tape to fix the VGA fan cable.
QOSMIO G20 Maintenance Manual (960-511) [CONFIDENTIAL] 4-57
To Next Page
