4.26 System board 4 Replacement Procedures
Installing the system board
The following describes the procedure for installing the system board (See Figure 4-39).
1. Connect the USB harness to the connector CN4611.
2. Connect the ODD flat cable to the connector CN1810.
3. Connect the SD board flat cable to the connector CN9500.
4. Connect the battery signal harness to the connector CN8811.
5. Connect the battery power harness to the connector CN8020.
6. Install the system board to the cover assembly.
NOTE: Confirm that volume harness is arranged in the right position while installing
the system board.
4-62 [CONFIDENTIAL] QOSMIO G20 Maintenance Manual (960-511)
