B.1 System Board Front View Appendix B Board Layout
Table B-1 System board ICs and connectors (front)
Mark Number Name
(a) IS2101 Bridge Media slot
(b) CN3400 Debugging port
(c) CN4400 Bluetooth FFC connector
(d) CN3330 Volume sensor cable connector
(e) CN3360 Touch sensor FFC connector
(f) CN8020 Battery power harness connector
(g) CN3201 Touch pad FFC connector
(h) CN8811 Battery signal harness connector
(i) CN3200 Keyboard I/F connector
(j) CN9500 Sound FFC I/F connector
(k) CN1810 ODD relay board I/F connector
(l) CN4611 USB harness connector
(m) CN5000 LCD harness connector
(n) CN4100 RJ45 harness connector
B-2 [CONFIDENTIAL] QOSMIO G20 Maintenance Manual (960-511)
