Appendix C Pin Assignment C.44 J9610 TV antenna connector (4-pin)
QOSMIO G20 Maintenance Manual (960-511) [CONFIDENTIAL] C-33
Antenna jack board (FNN2A*)
C.44 J9610 TV antenna connector (4-pin)
Table C-44 TV antenna connector (4-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 (CN9611-3) I/O 2 (CN9611-1) I/O
3 (CN9611-2) I/O 4 (CN9611-4) I/O
C.45 CN9611 Coaxial connector (4-pin)
Table C-45 Coaxial connector (4-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 (CN9610-2) I/O 2 (CN9610-3) I/O
3 (CN9610-1) I/O 4 (CN9610-4) I/O
