Toshiba TECRA A9 Series Maintenance Manual

1 Hardware Overview
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] 1-iii
Chapter 1 Contents
1.1 Features.......................................................................................................................1-1
1.2 System Unit Block Diagram.......................................................................................1-8
1.3 3.5-inch Floppy Disk Drive (USB External)............................................................1-14
1.4 2.5-inch Hard Disk Drive .........................................................................................1-15
1.5 Optical Drive (ODD)................................................................................................1-16
1.6 Keyboard .................................................................................................................1- 19
1.7 TFT Color Display ..................................................................................................1- 20
1.7.1 LCD Module ......................................................................................1- 20
1.7.2 FL Inverter Board ..............................................................................1- 21
1.8 Power Supply...........................................................................................................1- 22
1.9 Batteries...................................................................................................................1- 27
1.9.1 Main Battery ......................................................................................1- 27
1.9.2 Battery Charging Control...................................................................1- 28
1.9.3 RTC battery........................................................................................1- 29
1.10 AC Adaptor .............................................................................................................1- 30

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
