Appendices Appendix C Pin Assignments
C-24 [CONFIDENTIAL]TECRA A9(S5/P5/S200) Maintenance Manual (960-633)
C.30 CN9540 Web Camera interface connector (3-pin)
Table C-30 Web Camera interface connector (3-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1
P5V
- 2
ZUSBCM-E3N
I
3
ZUSBCM-E3P
I 4
GND
-
5
GND
- 6
GND
-
C.31 CN9550 Fingerprint sensor board interface connector (8-pin)
Table C-31 System board interface connector (8-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 GND - 2 ZUSBFS-E3P I/O
3 ZUSBFS-E3N I/O 4 GND -
5 FGSPON-S3N I 6 E3V I
7 8 GND
1T GND - 2T GND -
C.32 CN9721 Switch interface connector (13-pin)
Table C-32 Switch interface connector (13-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1
PNLOFF-S3N
I 2
S3V
-
3
4
GND
-
5
6
7
PWRSW-S3N
I 8
9
10
GPBTNA-S3N
I
11
12
13
GPBTNB-S3N
I
1T
GND
- 2T
GND
-
